OpenWeather

Packet Parser → HTTP

Submitted by

Last updated: 03. 2026

OpenWeather Official Website

OpenWeather is a weather data provider offering global weather information through a REST API. The TapHome template connects to the free OpenWeather API v2.5 via HTTPS and reads current weather conditions, a 3-hour forecast and a 24-hour forecast for a configured location.

The template makes two API calls every 5 minutes — one for current weather and one for the 5-day/3-hour forecast. It provides 18 read-only devices covering air temperature, feels-like temperature, humidity, atmospheric pressure, visibility, wind speed and weather conditions. All temperatures are in Celsius (metric units) and no paid subscription is required.

Configuration

Obtaining the API key

Register a free account at openweathermap.org — no credit card required
After registration, the API key (APPID) is sent via confirmation email
The key is also available on the account page under the API key tab
New keys activate automatically, typically within 10 minutes to 2 hours

The free tier allows 60 calls per minute and 1,000,000 calls per month. The TapHome template makes approximately 576 calls per day (2 calls every 5 minutes), which is well within the free limits.

Import parameters

When importing the template in TapHome, three parameters are required:

Parameter	Description	Example
`latitude`	Location latitude in decimal degrees	`48.1778`
`longitude`	Location longitude in decimal degrees	`17.1426`
`appid`	OpenWeather API key from account dashboard	`a1b2c3d4e5f6...`

To find the coordinates for a location, right-click on Google Maps and select the coordinates from the context menu.

API endpoints

The module connects to api.openweathermap.org over HTTPS (port 443) and calls two endpoints per poll cycle:

1
2
GET /data/2.5/weather?units=metric&lat={latitude}&lon={longitude}&appid={AppId}
GET /data/2.5/forecast?units=metric&lat={latitude}&lon={longitude}&appid={AppId}&cnt=9

The first request returns current weather conditions. The second returns a forecast list where list[0] is the next 3-hour slot and list[8] is the +24-hour slot (8 x 3h = 24h).

Device capabilities

The template exposes 18 read-only devices organized into three groups: current weather (6 devices), 3-hour forecast (6 devices) and 24-hour forecast (6 devices). Each group provides the same six measurements.

Temperature and humidity

Current Air Temperature — current temperature in Celsius with humidity as a secondary value (API returns 0–100%, converted to 0–1 ratio for TapHome)
Current Feels Like Temperature — apparent temperature accounting for wind chill and humidity. The humidity capability is disabled (returns NaN) — only the temperature value is used
Forecast (+3h) Air Temperature — temperature and humidity for the next 3-hour forecast slot. Includes a Forecast Date service attribute showing the timestamp of the data point
Forecast (+3h) Feels Like Temperature — apparent temperature for the next 3-hour slot
Forecast (+24h) Air Temperature — temperature and humidity for the +24h forecast slot. Includes a Forecast Date service attribute
Forecast (+24h) Feels Like Temperature — apparent temperature for the +24h slot

Atmospheric pressure and visibility

Current Air Pressure — atmospheric pressure in hPa
Current Visibility — visibility distance in meters (maximum 10,000 m)
Forecast (+3h) Air Pressure — atmospheric pressure for the next 3-hour slot
Forecast (+3h) Visibility — visibility for the 3-hour forecast
Forecast (+24h) Air Pressure — atmospheric pressure for the +24h slot
Forecast (+24h) Visibility — visibility for the 24-hour forecast

The Forecast (+3h) Visibility and Forecast (+24h) Visibility devices have their data indices swapped in the current template version. The +3h device reads from list[8] (the 24h position) and the +24h device reads from list[0] (the 3h position). The values are reversed until this is corrected in a future template update.

Wind speed

Current Wind Speed — wind speed in m/s
Forecast (+3h) Wind Speed — wind speed for the next 3-hour slot
Forecast (+24h) Wind Speed — wind speed for the +24h slot

Weather conditions

Three multi-value switch devices display the weather condition category:

Current Weather — current weather condition
Forecast (+3h) Weather — weather condition for the next 3-hour slot
Forecast (+24h) Weather — weather condition for the +24h slot

Each weather device maps the API weather[0].main field to one of 7 categories:

Switch Value	Label	API weather groups
0	Clear	Clear
1	Clouds	Clouds
2	Rain	Rain
3	Drizzle	Drizzle
4	Thunderstorm	Thunderstorm
5	Snow	Snow
6	Atmosphere	Mist, Smoke, Haze, Dust, Fog, Sand, Ash, Squall, Tornado

If the API returns an unrecognized weather group, the switch defaults to 0 (Clear). Switch values 7, 8 and 9 are defined in the template configuration but have no mapping in the script logic — they are unused placeholders.

Additional capabilities

The OpenWeather API also provides wind direction, wind gusts, cloudiness percentage, rain and snow volume (1h), and sunrise/sunset times. Humidity is only exposed as a secondary value on temperature sensors, not as a standalone device. These can be added in a future template update.

Troubleshooting

All devices show NaN or no data

Verify that the TapHome Core has internet access — the template requires outbound HTTPS connectivity to api.openweathermap.org
Check that the API key is valid — open https://api.openweathermap.org/data/2.5/weather?lat=48.18&lon=17.14&appid=YOUR_KEY&units=metric in a browser to test
New API keys may take up to 2 hours to activate after registration
Confirm the latitude and longitude values are correct decimal coordinates (not degrees/minutes/seconds)

Forecast data seems incorrect

The forecast API returns data in 3-hour intervals. The +3h devices read the first forecast slot (list[0]), which is the next available 3-hour block — not exactly 3 hours from now. Similarly, the +24h devices read list[8] (the 9th slot), which represents approximately 24 hours ahead.

Note the visibility index swap described in the warning above — if the +3h and +24h visibility values seem exchanged, this is the known template bug.

Device name typo

Device #17 in the template is named “Forecast (+24h)Weather” (missing space before “Weather”). This is a cosmetic issue in the template XML and does not affect functionality. The device is displayed correctly in the TapHome device table using its enriched name.

Available devices

OpenWeather Module

Custom Variables

`longitude` (string)	Geographic longitude of the weather station location in decimal degrees (set during import)
`latitude` (string)	Geographic latitude of the weather station location in decimal degrees (set during import)
`AppId` (string)	OpenWeather API key (obtain free key at openweathermap.org/api)

OpenWeather

Read (module)

responseJson := "error";
Daily := "error";

VAR path := "data/2.5/weather?units=metric&lat=" + latitude + "&lon=" + longitude + "&appid=" + AppId;
VAR response := SENDHTTPREQUEST(path);

IF response.IsSuccess
    responseJson := response.Content;
ELSE
    VAR contentJson := response.Content;
    VAR errCode := response.StatusCode;
    VAR message := PARSEJSON(contentJson, "message");
    #ADDERROR("Failed to read data - (" + errCode + ") " + message);
END

path := "data/2.5/forecast?units=metric&lat=" + latitude + "&lon=" + longitude + "&appid=" + AppId + "&cnt=9";
response := SENDHTTPREQUEST(path);

IF response.IsSuccess
    Daily := response.Content;
ELSE
    contentJson := response.Content;
    errCode := response.StatusCode;
    message := PARSEJSON(contentJson, "message");
    #ADDERROR("Failed to read data - (" + errCode + ") " + message);
END

Current Air Pressure Variable Read-only

numeric Unit: hPa json_path

Current Air Pressure

Read

IF(ISNULL(responseJson) | responseJson = "error", NaN, PARSEJSON(responseJson,"main.pressure"))

Read (module)

IF(ISNULL(responseJson) | responseJson = "error", ADDERROR("Failed to read data "));

Current Air Temperature Temperature Sensor Read-only

Current temperature and humidity — humidity is divided by 100 (API returns 0–100%, TapHome expects 0–1 ratio)

numeric Unit: °C json_path

Current Air Temperature

Read humidity

IF(ISNULL(responseJson) | responseJson = "error", NaN, PARSEJSON(responseJson,"main.humidity") / 100)

Read (module)

IF(ISNULL(responseJson) | responseJson = "error", ADDERROR("Failed to read data "));

Read temperature

IF(ISNULL(responseJson) | responseJson = "error", NaN, PARSEJSON(responseJson,"main.temp"))

Current Feels Like Temperature Temperature Sensor Read-only

Apparent temperature accounting for wind chill and humidity — humidity capability is disabled (returns NaN)

numeric Unit: °C json_path

Current Feels Like Temperature

Read humidity

NaN

Read (module)

IF(ISNULL(responseJson) | responseJson = "error", ADDERROR("Failed to read data "));

Read temperature

IF(ISNULL(responseJson) | responseJson = "error", NaN, PARSEJSON(responseJson,"main.feels_like"))

Current Visibility Variable Read-only

Visibility distance in meters (maximum 10,000 m)

numeric Unit: m json_path

Current Visibility

Read

IF(ISNULL(responseJson) | responseJson = "error", NaN, PARSEJSON(responseJson,"visibility"))

Read (module)

IF(ISNULL(responseJson) | responseJson = "error", ADDERROR("Failed to read data "));

Current Weather Multi-value Switch Read-only

Weather condition as multi-value switch — Clear, Clouds, Rain, Drizzle, Thunderstorm, Snow, Atmosphere

string multi_value_switch

Values / States: Clear · Clouds · Rain · Drizzle · Thunderstorm · Snow · Atmosphere

Current Weather

Read switch state

IF(ISNULL(responseJson) | responseJson = "error")
    return(NaN);
END

VAR weather := PARSEJSON(responseJson, "weather[0].main");
SWITCH(weather, "Clear", 0, "Clouds", 1, "Rain", 2, "Drizzle", 3, "Thunderstorm", 4, "Snow", 5, "Mist", 6, "Smoke", 6, "Haze", 6, "Dust", 6, "Fog", 6, "Sand", 6, "Ash", 6, "Squall", 6, "Tornado", 6, 0);

Read (module)

IF(ISNULL(responseJson) | responseJson = "error", ADDERROR("Failed to read data "));

Current Wind Speed Variable Read-only

numeric Unit: m/s json_path

Current Wind Speed

Read

IF(ISNULL(responseJson) | responseJson = "error", NaN, PARSEJSON(responseJson,"wind.speed"))

Read (module)

IF(ISNULL(responseJson) | responseJson = "error", ADDERROR("Failed to read data "));

Forecast (+3h) Air Pressure Variable Read-only

numeric Unit: hPa json_path

Forecast (+3h) Air Pressure

Read

IF(ISNULL(Daily) | Daily = "error", NaN, PARSEJSON(Daily,"$.list[0].main.pressure"))

Read (module)

IF(ISNULL(responseJson) | responseJson = "error", ADDERROR("Failed to read data "));

Forecast (+3h) Air Temperature Temperature Sensor Read-only

Temperature and humidity for the next 3-hour forecast slot — includes Forecast Date service attribute

numeric Unit: °C json_path

Service Attributes

Forecast Date

Timestamp of the forecast data point (dt_txt from API response)

Forecast (+3h) Air Temperature

Read humidity

IF(ISNULL(Daily) | Daily = "error", NaN, PARSEJSON(Daily,"$.list[0].main.humidity") / 100)

Read (module)

IF(ISNULL(Daily) | Daily = "error", ADDERROR("Failed to read data "));

Read temperature

IF(ISNULL(Daily) | Daily = "error", NaN, PARSEJSON(Daily,"$.list[0].main.temp"))

Service Attributes

Forecast Date

IF(ISNULL(Daily) | Daily = "error", NaN, PARSEJSON(Daily,"$.list[0].dt_txt"))

Forecast (+3h) Feels Like Temperature Temperature Sensor Read-only

Apparent temperature for the next 3-hour forecast slot — humidity capability is disabled (returns NaN)

numeric Unit: °C json_path

Forecast (+3h) Feels Like Temperature

Read humidity

NaN

Read (module)

IF(ISNULL(responseJson) | responseJson = "error", ADDERROR("Failed to read data "));

Read temperature

IF(ISNULL(Daily) | Daily = "error", NaN, PARSEJSON(Daily,"$.list[0].main.feels_like"))

Forecast (+3h) Visibility Variable Read-only

Known issue: reads from list[8] instead of list[0] — visibility values are swapped with Forecast (+24h)

numeric Unit: m json_path

Forecast (+3h) Visibility

Read

IF(ISNULL(Daily) | Daily = "error", NaN, PARSEJSON(Daily,"$.list[8].visibility"))

Read (module)

IF(ISNULL(responseJson) | responseJson = "error", ADDERROR("Failed to read data "));

Forecast (+3h) Weather Multi-value Switch Read-only

Weather condition for the next 3-hour forecast slot — same 7-category mapping as Current Weather

string multi_value_switch

Values / States: Clear · Clouds · Rain · Drizzle · Thunderstorm · Snow · Atmosphere

Forecast (+3h) Weather

Read switch state

IF(ISNULL(Daily) | Daily = "error")
    return(NaN);
END

VAR weather := PARSEJSON(Daily, "$.list[0].weather[0].main");
SWITCH(weather, "Clear", 0, "Clouds", 1, "Rain", 2, "Drizzle", 3, "Thunderstorm", 4, "Snow", 5, "Mist", 6, "Smoke", 6, "Haze", 6, "Dust", 6, "Fog", 6, "Sand", 6, "Ash", 6, "Squall", 6, "Tornado", 6, 0);

Read (module)

IF(ISNULL(Daily) | Daily = "error", ADDERROR("Failed to read data "));

Forecast (+3h) Wind Speed Variable Read-only

numeric Unit: m/s json_path

Forecast (+3h) Wind Speed

Read

IF(ISNULL(Daily) | Daily = "error", NaN, PARSEJSON(Daily,"$.list[0].wind.speed"))

Read (module)

IF(ISNULL(responseJson) | responseJson = "error", ADDERROR("Failed to read data "));

Forecast (+24h) Air Pressure Variable Read-only

numeric Unit: hPa json_path

Forecast (+24h) Air Pressure

Read

IF(ISNULL(Daily) | Daily = "error", NaN, PARSEJSON(Daily,"$.list[8].main.pressure"))

Read (module)

IF(ISNULL(responseJson) | responseJson = "error", ADDERROR("Failed to read data "));

Forecast (+24h) Air Temperature Temperature Sensor Read-only

Temperature and humidity for the +24h forecast slot — includes Forecast Date service attribute

numeric Unit: °C json_path

Service Attributes

Forecast Date

Timestamp of the forecast data point (dt_txt from API response)

Forecast (+24h) Air Temperature

Read humidity

IF(ISNULL(Daily) | Daily = "error", NaN, PARSEJSON(Daily,"$.list[8].main.humidity") / 100)

Read (module)

IF(ISNULL(Daily) | Daily = "error", ADDERROR("Failed to read data "));

Read temperature

IF(ISNULL(Daily) | Daily = "error", NaN, PARSEJSON(Daily,"$.list[8].main.temp"))

Service Attributes

Forecast Date

IF(ISNULL(Daily) | Daily = "error", NaN, PARSEJSON(Daily,"$.list[8].dt_txt"))

Forecast (+24h) Feels Like Temperature Temperature Sensor Read-only

Apparent temperature for the +24h forecast slot — humidity capability is disabled (returns NaN)

numeric Unit: °C json_path

Forecast (+24h) Feels Like Temperature

Read humidity

NaN

Read (module)

IF(ISNULL(responseJson) | responseJson = "error", ADDERROR("Failed to read data "));

Read temperature

IF(ISNULL(Daily) | Daily = "error", NaN, PARSEJSON(Daily,"$.list[8].main.feels_like"))

Forecast (+24h) Visibility Variable Read-only

Known issue: reads from list[0] instead of list[8] — visibility values are swapped with Forecast (+3h)

numeric Unit: m json_path

Forecast (+24h) Visibility

Read

IF(ISNULL(Daily) | Daily = "error", NaN, PARSEJSON(Daily,"$.list[0].visibility"))

Read (module)

IF(ISNULL(responseJson) | responseJson = "error", ADDERROR("Failed to read data "));

Forecast (+24h) Wind Speed Variable Read-only

numeric Unit: m/s json_path

Forecast (+24h) Weather Multi-value Switch Read-only

Weather condition for the +24h forecast slot — same 7-category mapping as Current Weather

string multi_value_switch

Values / States: Clear · Clouds · Rain · Drizzle · Thunderstorm · Snow · Atmosphere

Forecast (+24h) Weather

Read switch state

IF(ISNULL(Daily) | Daily = "error")
    return(NaN);
END

VAR weather := PARSEJSON(Daily, "$.list[8].weather[0].main");
SWITCH(weather, "Clear", 0, "Clouds", 1, "Rain", 2, "Drizzle", 3, "Thunderstorm", 4, "Snow", 5, "Mist", 6, "Smoke", 6, "Haze", 6, "Dust", 6, "Fog", 6, "Sand", 6, "Ash", 6, "Squall", 6, "Tornado", 6, 0);

Connection: Packet Parser → HTTP

Possible improvements (7)

Current Humidity (standalone) — Humidity is only exposed as secondary value on temperature sensors, not as standalone device
Wind Direction — Wind direction in degrees available in API but not implemented in template
Wind Gust — Wind gust speed available in API but not implemented in template
Cloudiness — Cloudiness percentage available in API but not implemented
Rain Volume (1h) — Rain volume for last 1 hour in mm, available in API
Snow Volume (1h) — Snow volume for last 1 hour in mm, available in API
Sunrise / Sunset — Unix timestamps for sunrise and sunset available in API

Download Template

Sources

Current Weather Data API 2.5
openweathermap.org 2026-03-28
5 Day / 3 Hour Forecast API
openweathermap.org 2026-03-28
Weather Condition Codes
openweathermap.org 2026-03-28
API Key Setup Guide
openweathermap.org 2026-03-28
