Meteosource Weather API

Packet Parser → HTTP

Submitted by

Last updated: 03. 2026

Meteosource Official Website

Meteosource is a global weather data provider offering current conditions, forecasts and historical data through a REST API. The TapHome template connects to the Meteosource free tier API via HTTPS and reads current weather conditions and today’s daily forecast for a configured GPS location.

The template provides 8 read-only devices covering weather type, wind speed and direction, current temperature, daily min/max temperatures and precipitation (current and daily). The module polls the API every 5 minutes and caches the full JSON response — individual sensors then read from the cache at faster intervals. The free tier allows 400 calls per day and the template uses approximately 288 calls per day, which is well within the limit.

Configuration

Obtaining the API key

Register a free account at meteosource.com/client/sign-up
After registration, the API key is available in the account dashboard
Copy the key — it will be needed when importing the template in TapHome

The free tier provides 400 API calls per day with a rate limit of 10 requests per minute. The TapHome template polls every 5 minutes (288 calls/day), which leaves a comfortable margin. The free tier requires a mention and backlink to Meteosource for commercial use.

Import parameters

When importing the template in TapHome, three parameters are required:

Parameter	Description	Example
`latitude`	Location latitude in decimal degrees	`48.1778`
`longitude`	Location longitude in decimal degrees	`17.1426`
`apiKey`	Meteosource API key from account dashboard	`abc123def456...`

To find the coordinates for a location, right-click on Google Maps and select the coordinates from the context menu.

Module variables

After importing the template, one variable can be adjusted in the module settings:

Variable	Description	Default
`tz`	Timezone in tzinfo format	`Europe/Prague`

The timezone determines how timestamps in the API response are interpreted. Users outside the CET/CEST timezone should change this value to match their location (e.g. America/New_York, Asia/Tokyo, UTC).

API endpoint

The module connects to www.meteosource.com over HTTPS (port 443) and calls:

1
GET /api/v1/free/point?lat={lat}&lon={lon}&sections=current,daily&timezone={tz}&language=en&units=ca&key={apiKey}

The template uses the ca (Canadian) unit system: Celsius for temperature, km/h for wind speed, mm for precipitation and hPa for pressure.

Device capabilities

Weather type

The Weather Type device is a multi-value switch that maps the Meteosource icon_num field (values 1–36) to 7 TapHome weather categories:

Switch Value	Category	Meteosource icons (day)	Meteosource icons (night)
0	Clear / Sunny	2, 3, 4, 5	26, 27, 28
1	Clouds / Overcast	6, 7, 8	29, 30, 31
2	Rain	11, 12, 13, 25	32, 34, 35, 36
3	Drizzle / Light rain	10	–
4	Thunderstorm	14, 15	33
5	Snow / Freezing	16–24	–
6	Fog	9	–

If the icon number is 1 or unrecognized, the switch defaults to 1 (Clouds). The weather type is polled every 30 minutes.

Temperature

Three temperature devices provide current and forecast data:

Temperature – current air temperature at 2m height in Celsius. Uses a dedicated temperature sensor device type with error reporting if the API response is unavailable
Temperature Max – today’s forecast maximum temperature in Celsius, read from the daily forecast section (daily.data[0])
Temperature Min – today’s forecast minimum temperature in Celsius, read from the daily forecast section (daily.data[0])

Wind

Wind Speed – current wind speed at 10m height in km/h (using the ca unit system). Reports an error if the cached response is unavailable
Wind Direction – wind direction in degrees (0–360, where 0/360 = North, 90 = East, 180 = South, 270 = West). This is the fastest-polled device at 15-second intervals, reading from the cached response

Precipitation

Precipitation (1-hour) – current precipitation amount in mm. Reports an error if the cached response is unavailable
Precipitation (Daily) – today’s total daily forecast precipitation in mm, read from the daily forecast section

Additional capabilities

The Meteosource API also exposes feels-like temperature, wind gusts, cloud cover, atmospheric pressure, humidity, visibility, UV index, dew point, wind chill, precipitation type and a text weather summary for current conditions. An air quality endpoint with PM10, PM2.5, NO2, CO, O3 and AQI is available separately. These can be added in a future template update.

Troubleshooting

All devices show NaN or no data

Verify that the TapHome Core has internet access – the template requires outbound HTTPS connectivity to www.meteosource.com
Check that the API key is valid and has not been regenerated
Confirm the latitude and longitude values are correct decimal coordinates
New API keys may require a few minutes to activate after registration

Stale or delayed readings

The module polls the Meteosource API every 5 minutes and stores the response in a cache variable. Individual sensors read from this cache at faster intervals (15 seconds to 1 minute). If the API call fails, all sensors continue returning their last cached values until the next successful poll.

The Meteosource API is a cloud service that requires an active internet connection on the TapHome Core. During internet outages or API downtime, the template will not receive updated weather data. The default timezone is Europe/Prague – users in other regions must change the tz module variable for correct local timestamps.

Available devices

Meteosource Module

Custom Variables

`apiKey` (string)	Meteosource API key for authentication (obtain from meteosource.com dashboard)
`lat` (string)	Geographic latitude of the weather location in decimal degrees (set during import)
`lon` (string)	Geographic longitude of the weather location in decimal degrees (set during import)
`tz` (string) = Europe/Prague	IANA timezone identifier for timestamp conversion (e.g. Europe/Prague, America/New_York)

Meteosource

Read (module)

VAR request := HTTPREQUEST(
	"/api/v1/free/point?lat=" + lat + "&lon=" + lon + "&sections=current,daily&timezone=" + tz + "&language=en&units=ca&key=" + apiKey,
	"GET"
);
VAR response := SENDHTTPREQUEST(request);
VAR responseHeaders := response.Headers;
IF response.IsSuccess
  responseJson := response.Content;
END

Weather Type Multi-value Switch Read-only

Weather condition as multi-value switch — Clear, Clouds, Rain, Drizzle, Thunderstorm, Snow, Fog

integer → mapped Unit: category JSON parsejson()

Values / States: ${weather_clear} · ${weather_clouds} · ${weather_rain} · ${weather_drizzle} · ${weather_thunderstorm} · ${weather_snow} · ${weather_fog}

Weather Type

Read switch state

IF(ISNULL(responseJson) | responseJson = "error")
    return(NaN);
END

VAR weather := PARSEJSON(responseJson, "current.icon_num");
SWITCH(weather,
2, 0, 3, 0, 4, 0,26,0, 27,0,28,0,
5, 0, 6, 1, 7, 1, 8,1,29,1,30,1,31,1,
	11,2,12,2,13,2,25,2,32,2,34,2,35,2,36,2,
10,3,
	16,5,17,5,18,5,19,5,20,5,21,5,22,5,23,5,24,5,
14,4,15,4,33,4,
9,6,
1);

Wind Speed Variable Read-only

numeric Unit: km/h JSON parsejson()

Wind Speed

Read

IF(
	ISNULL(responseJson) | responseJson = "error",
	NaN,
	TODOUBLE(PARSEJSON(responseJson,
		"current.wind.speed"))
);

Read (module)

IF(ISNULL(responseJson) | responseJson = "error", ADDERROR("Failed to read data "));

Wind Direction Variable Read-only

Wind direction in degrees — 0/360 = North, 90 = East, 180 = South, 270 = West

numeric Unit: ° JSON parsejson()

Temperature Temperature Sensor Read-only

numeric Unit: °C JSON parsejson()

Temperature

Read (module)

IF(ISNULL(responseJson) | responseJson = "error", ADDERROR("Failed to read data "));

Read temperature

IF(ISNULL(responseJson) | responseJson = "error", NaN, TODOUBLE(PARSEJSON(responseJson,"current.temperature")))

Temperature Max Variable Read-only

Today's forecast maximum temperature from the daily forecast section

numeric Unit: °C JSON parsejson()

Temperature Min Variable Read-only

Today's forecast minimum temperature from the daily forecast section

numeric Unit: °C JSON parsejson()

Precipitation (1-hour) Variable Read-only

numeric Unit: mm JSON parsejson()

Precipitation (1-hour)

Read

IF(ISNULL(responseJson) | responseJson = "error", NaN, TODOUBLE(PARSEJSON(responseJson,"current.precipitation.total")))

Read (module)

IF(ISNULL(responseJson) | responseJson = "error", ADDERROR("Failed to read data "));

Precipitation (Daily) Variable Read-only

Today's total daily forecast precipitation from the daily forecast section

numeric Unit: mm JSON parsejson()

Connection: Packet Parser → HTTP

Possible improvements (12)

Feels Like Temperature — Perceived temperature accounting for wind chill and humidity. Float, Celsius with ca units
Wind Gusts — Peak wind gust speed at 10m. Float, km/h with ca units
Cloud Cover — Total cloud cover percentage. Integer, 0–100%
Atmospheric Pressure — Sea level atmospheric pressure. Float, hPa with ca units
Relative Humidity — Relative humidity. Integer, 0–100%
Visibility — Visibility distance. Float, km with ca units
UV Index — UV radiation index. Float, 0–11+ scale
Dew Point — Dew point temperature. Float, Celsius with ca units
Wind Chill — Wind chill temperature. Float, Celsius with ca units
Precipitation Type — Type of precipitation — none, rain, snow, rain_snow, ice_pellets, frozen_rain. String value
Weather Summary — Human-readable text description of current weather. Translated per language parameter
Air Quality Index — Requires separate /air_quality endpoint. Includes PM10, PM2.5, NO2, CO, O3, AQI (1–6 scale). Not available via Point endpoint
